Startech.com RS232EXTC1 Serial DB9 RS232 Extender Over Cat 5 up to 3300 ft 1000

Extend an RS232 serial connection up to 1000 meters (3300 feet) using Cat 5 cabling.

The Startech.com RS232EXTC1 Serial DB9 RS232 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system - an incredible 65x greater than normal RS232 serial cable length restrictions would permit. The extender is a cost-effective serial extension solution and completely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation. The hardware can be set up in minutes, using existing or Cat 5 or better Ethernet cabling.

Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps. Backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage

• Provides you with flexibility when choosing the location of your serial peripherals by dramatically increasing the maximum RS232 serial cable length
• Pure hardware design, no software or drivers required ensuring a simple plug and play installation
• Enables use of separate control rooms away from harsh environmental conditions where serial devices may be located

Product Features:

• Type: Network receiver
• Maximum transfer distance: 1000
• Cable types supported: Cat5
• Cabling technology: 10/100Base-T(X)
• Ethernet LAN (RJ-45) ports: 2
• Input current: 0.055
• Output voltage: 9
• Operating temperature (T-T): 0 - 70
• Storage temperature (T-T): 0 - 85
• Operating relative humidity (H-H): 0 - 95
• Width: 34
• Depth: 92
• Height: 22
• Weight: 65
• Product color: Silver
• RoHS compliance: Y
• Package width: 57
• Package depth: 315
• Package height: 138

Learn More:

RS-232 on Wikipedia

Cat 5 Cable on Wikipedia

Product: Startech.com RS232EXTC1 Serial DB9 RS232 Extender Over Cat 5 up to 3300 ft 1000

Brand: Startech.Com

Model: RS232EXTC1

Shipping Weight: 1.45 lb

Shipping Height: 2.50 in

Shipping Width: 5.50 in

Shipping Length: 12.50 in
