Startech.com ICUSB2324852 USB to RS232/RS422/RS485 Adapter

Product Description:

The Startech.com ICUSB2324852 USB to RS232/RS422/RS485 Adapter is a versatile cable interface/gender adapter that allows you to connect any type of serial device to your USB-enabled computer. Whether you need RS232, RS422, or RS485 communication, this adapter has got you covered. With its 9-pin (DB9) male connector and 5-pin terminal block serial connector, as well as dip-switch controls for easy port configuration, this adapter provides a convenient solution for your serial connectivity needs. It also supports using two ports simultaneously, including mixed protocols.

For a hassle-free installation in office or industrial settings, the RS232/RS422/RS485 USB Adapter is wall-mountable and fully powered via the host USB connection. This means you don't need an external power adapter, as the adapter provides power to the attached serial device. Backed by a StarTech.com 2-year warranty and free lifetime technical support, this adapter ensures reliable performance and peace of mind.

Product Features:

• Compatible with any serial device protocol (RS232, RS422, and RS485)
• Allows mixing protocols for simultaneous communication over both ports
• COM retention saves the assigned port settings for the device, ensuring hassle-free disconnecting/reconnecting
• USB Powered - no need for a power outlet or external power adapter

Specifications:

• Connector gender: Male connector/Male connector
• Connector 1: USB 2.0 A
• Connector 2: DB-9
• Package weight: 310g
• Product color: Grey
• Height: 23.2mm
• Depth: 82.3mm
• Width: 44.2mm
• Compatible operating systems:
  • - Windows CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10
  • - Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016
  • - Mac OS X® 10.6 to 10.12
  • - Linux 2.4.x to 4.4.x LTS
• Operating temperature (T-T): 0&degC - 55&degC
• Storage temperature (T-T): -25&degC - 85&degC
• Relative humidity: 5% - 95%
• Package height: 40mm
• Package width: 144mm
• Package depth: 208mm
• Quantity per pack: 1
• Cables included: USB
• Manual: Yes
• Chipset: FTDI - FT2232H
• Certification: CE, FCC
• Data bits: 7, 8
• FIFO (First In, First Out): 128
• Baud rate: 921.6
• Flow Control type: N, XON/XOFF
• Parity bit: Even, Mark, N, Odd, Space
• Stop bits: 1, 2
• Output voltage: 5V
• Output current: 385mA
• LED indicators: Power
• Power plug: B
• Housing material: Plastic
• Weight: 310g
• RoHS compliance: Yes

Learn More:

For more information about USB to RS232/RS422/RS485 adapters, please visit the USB-to-RS-232 Adapters Wikipedia page.

To learn about the different types of serial communication protocols, including RS232, RS422, and RS485, you can visit the Types of Serial Communication Wikipedia page.

Product: STARTECH.COM ICUSB2324852 ADD RS232 RS422 AND RS485 SUPPORT TO YOUR LAPTOP OR

Brand: Startech.Com

Model: ICUSB2324852
