Shuttle DH670 System 1.3L Chassis Core I3/I5/I7/I9 Lga1700 H670 Max64Gb Ddr4 Re

Overview

The Shuttle DH670 System is a compact and powerful PC designed for a wide range of applications, including digital signage and kiosk solutions. With its 1.3L slim chassis design, this system offers impressive expandability and connectivity options. It supports Intelr 12th-Gen Alder Lake hybrid architecture, allowing for a combination of high-performance cores and high-efficiency cores. Equipped with a 65W base power processor, the DH670 can handle up to 16 cores and 24 threads. The integrated Intelr UHD graphics processor delivers stunning clarity for 4K/60P UHD resolution, enabling enhanced performance in AI and computer vision applications. This black-colored system is built with a durable metal housing and features a range of interfaces for seamless connectivity.

Features

• Product type: Mini PC (<= 3L) barebone
• Motherboard chipset: Intel H670
• Number of power supply units: 1
• Operating relative humidity (H-H): 10 - 90
• Operating temperature (T-T): 0 - 50
• AC adapter included: Yes
• Ethernet LAN: Yes
• Ethernet LAN (RJ-45) ports: 2
• Built-in speaker(s): No
• Cable lock slot type: Kensington
• Supported storage drive types: HDD & SSD
• VESA mounting: Yes
• Number of memory slots: 2
• USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
• USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
• Power cord included: Yes
• Audio output channels: 2.0
• LED indicators: HDD, Power
• Quick start guide: Yes
• Housing material: Metal
• HDMI version: 2.0b
• Memory voltage: 1.2
• BIOS type: UEFI AMI
• Weight: 1300g
• Power supply type: External AC adapter
• Compatible processor series: Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold
• Compatible memory cards: SD, SDHC, SDXC
• Chassis type: 1.3L sized PC
• Package weight: 2100g
• HDMI ports quantity: 2
• AC adapter output voltage: 19
• AC adapter output current: 6.32
• Trusted Platform Module (TPM): Yes
• Maximum internal memory: 64GB
• Power supply: 120W
• Serial ports quantity: 2
• Cable lock slot: Yes
• Height: 43mm
• Built-in processor: No
• Memory slots type: SO-DIMM
• Supported memory clock speeds: 2133, 2400, 2666, 2933, 3200
• Supported memory types: DDR4-SDRAM
• Non-ECC: Yes
• Memory channels: Dual-channel
• Storage drive sizes supported: 2.5", M.2
• Storage drive interface: M.2, Serial ATA III
• Number of storage drives supported: 2
• Card reader integrated: Yes
• On-board graphics card: Yes
• Graphics card family: Intel
• Wi-Fi: No
• Microphone in: Yes
• Headphone outputs: 1
• DisplayPorts quantity: 2
• DisplayPort version: 1.4
• DC-in jack: Yes
• Product color: Black
• Cooling type: Active
• Panel mounting interface: 75 x 75, 100 x 100
• Processor socket: LGA 1700
• Number of processors supported: 1
• Trusted Platform Module (TPM) version: 2.0
• Windows operating systems supported: Windows 10, Windows 11

Product: Shuttle DH670 System 1.3L Chassis Core I3/I5/I7/I9 Lga1700 H670 Max64Gb Ddr4 Re

Brand: Shuttle

Model: DH670
