Schaefer 504-82 Marine Aluminum 1" T-Track Spring Loaded Slide

Spring Loaded/Lined Slide/Aluminum for 1" T-Track

Upgrade your boat's rigging system with the Schaefer 504-82 Marine Aluminum 1" T-Track Spring Loaded Slide. Designed for smooth operation and maximum strength, this slide is perfect for optimizing your sailing experience. The Delrin™ sheave ensures smooth operation and offers a high safe working load, while the anodized aluminum cheeks and stainless steel slider provide exceptional reliability. With its polyethylene liner and pin stop, adjusting and fine-tuning your sail setup has never been easier.

Product Features:

• Spring-loaded and lined slide for 1" T-Track
• Delrin™ sheave ensures smooth operation and high safe working load
• Anodized aluminum cheeks and stainless steel slider ensure reliability
• Polyethylene liner and pin stop allow for easy adjustment

Specifications:

• Track Size: 1" x 1/8" (25 mm x 3 mm)
• Max. Boat Length: 27' (8m)
• Max. Boat Weight: 5000 lbs. (2270 kgs)
• Sail Area: 315 sq. ft (29 m2)
• Sheave Diameter: 2" (51 mm)
• Max Line: 7/16" (11 mm)
• Length: 3" (76 mm)
• Width: 1-1/4" (31 mm)
• Height: 4-5/32" (105 mm)
• Bearing Height: 2-7/32" (56 mm)
• SWL: 1750 lbs. (795 kg)
• Weight: 7.0 oz. (198 g)

Learn More:

For more information about T-Track systems, visit the T-Track Wikipedia page.

To learn more about sailing and rigging components, check out the Sailing Wikipedia page.

Product: Schaefer Marine 504-82 Spring Loaded/Lined Slide/Aluminum 1" T-Track

Brand: Schaefer Marine

Model: 504-82

Shipping Weight: 0.55 lb

Shipping Height: 2.00 in

Shipping Width: 3.00 in

Shipping Length: 5.00 in
