Mastervolt 35512000 Combimaster 12/2000 Inverter/Charger 12V Input 120V

The Mastervolt 35512000 Combimaster 12/2000 Inverter/Charger is designed with the customer in mind, providing user-friendliness and reliability. It is the most compact and lightweight Combi in its class, making it easy to install and transport. This powerful inverter/charger ensures a constant power supply and can start even the heaviest and most sensitive loads effortlessly.

Key Features:

• Compact and lightweight design
• Reliable and hum-free operation
• Starts heavy and sensitive loads
• Intelligent 3-step+ battery charger for faster and safer charging
• Automatic switching between mains and inverter mode
• Power Assist function prevents blown mains fuses
• Generator compatible
• Integrated CZone, MasterBus, and NMEA 2000 communication
• Quick installation with heavy-duty connections
• E-mark certified

Specifications

Sine Wave Inverter

• Nominal DC voltage: 12 V (10.2-16 V)
• Output voltage: 120 V
• Output frequency: 60/50 Hz (configurable)
• Output waveform: True sine
• Continuous power at 40 &degC / 104 &degF, cos phi: 12000 W
• Peak power (30 sec): 3000 W
• Surge power (5 sec): 4000 W
• Max. efficiency: 93 %
• Battery no-load power consumption: 30 W (on mode) / < 1 mA (off mode)
• Energy saving mode consumption: 10 W
• Synchronise with mains: Yes

Battery Charger

• Input voltage range: 90-140 V
• Max. input current: 17 A (adjustable)
• Max. charge current at 40 &degC / 104 &degF: 100 A at 14.25 V (configurable)
• Battery temperature sensor: Yes, included
• Battery voltage sense: Automatic compensation

Transfer System

• AC input: 30 A (switched)
• AC output: 47 A
• AC input fuse: Yes
• Transfer speed: 10 ms
• Transfer voltage range: Wide: 70-140 V / Narrow: 90-140V
• Transfer frequency range: 40-65 Hz

General Specifications

• Galvanic isolation: Yes
• Display/read-out: LED display
• Dimensions (hxwxd): 17.6 x 11.2 x 6.1 inch
• Weight: 20.5 lb
• Compliance: ABYC A31, UL1236, UL1741, SAEJ1171, FCC class B

Technical Specifications

• Charge characteristic: UoUo, automatic / 3-step+ for flooded, Gel/AGM and MLI, configurable
• Recommended battery capacity: 180-500 Ah (based on gel batteries, may differ for other types)
• Ground relay: Yes, configurable by means of mechanical jumper
• Temperature range (ambient temp.): -13 &degF to 140 &degF

The Mastervolt 35512000 Combimaster 12/2000 Inverter/Charger offers unmatched performance and value for money. It is compatible with MasterBus, CZone, and NMEA 2000 communication, allowing for a broad range of monitoring and system integration options.

Learn More

• Inverter
• Battery Charger
• AC Power Plugs and Sockets

Product: Mastervolt 35512000 Combimaster 12/2000 Inverter/Charger 12V Input 120V

Brand: Mastervolt

Model: 35512000
