SIGNATURE SPORT SERIES 3i MARINE SUBWOOFER (FUSION)

Fusion Signature Series 3i Marine Subwoofers 12" 1400-watt CRGBW Sports Gray Marine Subwoofer

• Crystal-clear premium sound quality is suited for the marine environment.
• Water-resistant connectors provide simplified installation and superior protection.
• The rigorously tested marinized design has an IP65 rating.
• Built to last season after season, the Signature Series 3i subwoofers include a supported 3-year warranty.
• Material enhancements and protective engineering maintain the sharp aesthetic appeal of your speakers, year after year.
• Any product that bears the Fusion True-Marine seal of assurance has been designed by Fusion to withstand the harshest marine environments season after season and comes with an industry-leading 3-year warranty.
• This technology provides exceptional self-dampening, high-fidelity and bass reproduction to give you the most premium onboard listening experience imaginable.
• These subwoofers are designed to work optimally with Fusion® stereo systems and amplifiers (sold separately) with custom DSP profiles. This requires the Fusion-Link smart-device app for setup.

Specifications

• Physical dimensions (diameter x depth)14.02" x 10" (356 x 254 mm)
• Weight24.1 lbs (10.93 kg)
• Water and dust ratingIP65
• Peak power (Watts)1400 watts
• RMS power rating (watts)700 WATTS
• Sensitivity (1 watt at 1 metre)86 dB
• Magnetic structure114 OZ
• Frequency response20 Hz—2 kHz
• Nominal impedance4 ohm
• Recommended amplifier power (watts RMS)200-1000 watts
• LED lightingyes, CRGBW (sports style with LED models only)
• LED supply voltage10.8—16 VDC (sports style with LED models only)
• LED load current at 14.4 VDC (max)300 mA (sports style with LED models only)
• Operating temperature range32—122 degrees F (0—50 degrees C)
• Voice coil diameter4"
• Cone materialPolypropylene cone with rubber surround
• Compass-safe distance181" (460 cm)
• Subwoofer connectionFlying lead with water-resistant 2-way connector, 5.9" (150 mm)
• LED connection (sports style with LED models only)Flying lead with water-resistant 6-way connector, 5.9" (150 mm)
• Warranty3 years

Mounting Dimensions

• Mounting diameter clearance12.05" (306 mm)
• Mounting depth clearance8.15" (207 mm)

Optimum enclosure recommendations

• Sealed enclosure volume (fully filled with absorption material)2.12 cubic ft (60 L)
• Ported (vented) enclosure volume (lined with absorption material)8.83 cubic ft (250 L)
• Port diameter4" (101.6 mm)
• Port length5" (127 mm)

What's in the Box:

• Signature Series 3i Marine Subwoofers 12" 1400-watt CRGBW Sports Gray Marine Subwoofer
• 6 Phillips stainless steel mounting screws, 4.8 mm x 50 mm (10 gauge x 2")
• Water-resistant cable assembly with 2-pin connector (5.9" (150 mm))
• Documentation
