POWERCOMBI INVERTER/CHARGER (MASTERVOLT)

The POWERCOMBI INVERTER/CHARGER (MASTERVOLT) is a versatile and reliable power solution designed with the customer in mind. With its compact and lightweight design, it is the most compact and lightweight Combi in its class. This powerful inverter/charger ensures a constant power supply, even for the heaviest and most sensitive loads.

Features:

• Reliable, hum-free, and longer operation from your batteries
• Starts even the heaviest and most sensitive loads
• Intelligent 3-step+ battery charger for faster and safer charging
• Automatic switching between mains and inverter mode
• Power Assist prevents blown mains fuses
• Generator compatible
• Integrated CZone, MasterBus, and NMEA 2000 communication
• Quick installation with heavy-duty connections
• E-mark certified

The POWERCOMBI INVERTER/CHARGER (MASTERVOLT) delivers unmatched performance and value for money. It is completed with MasterBus, CZone, and NMEA 2000 compatible communication, allowing for a broad range of monitoring and system integration options.

Specifications:

• Nominal DC voltage: 24 V (20.4—32 V)
• Output voltage: 120 V
• Output frequency: 60/50 Hz (configurable)
• Output waveform: true sine
• Continuous power at 40 &degC / 104 &degF, cos phi: 12000 W
• Peak power (30 sec): 3000 W
• Surge power (5 sec): 4000 W
• Max. efficiency: 93 %
• Battery no-load power consumption: 30 W (on mode) / < 1 mA (off mode)
• Energy-saving mode consumption: 10 W
• Synchronize with mains: yes
• Input voltage range: 90—140 V
• Max. input current: 21 A (adjustable)
• Max. charge current at 40 &degC / 104 &degF: 60 A at 28.5 V (configurable)
• Battery temperature sensor: yes, included
• Battery voltage sense: automatic compensation
• AC input: 30 A (switched)
• AC output: 47 A
• AC input fuse: yes
• Transfer speed: 10 ms
• Transfer voltage range: wide: 70—140 V / narrow: 90—140V
• Transfer frequency range: 40-65 Hz
• Galvanic isolation: yes
• Display/read-out: LED display
• Dimensions, hxwxd: 17.6 x 11.2 x 6.1 inch
• Weight: 20.5 lb
• Compliance: ABYC A31, UL1236, UL1741, SAEJ1171, FCC class B
• Charge characteristic: UoUo, automatic / 3-step+ for flooded, Gel/AGM and MLI, configurable
• Recommended battery capacity: 120-320 Ah (based on gel batteries, may differ for other types)
• Ground relay: yes, configurable by means of mechanical jumper
• Temperature range (ambient temp.): -13 &degF to 140 &degF
