Fusion SM-F65CW 6.5 White Shallow Mount Square Speakers - SM Series 010-02263-10

Introducing the Fusion SM-F65CW SM Series 6.5" Shallow Mount Square Speakers in White Cloth Grill. These speakers are designed to deliver exceptional sound quality while maintaining a unique shallow mount design. With a maximum power output of 100W, these speakers are perfect for installations where mounting depth is limited.

The SM Series speakers are engineered with a sealed, perfectly-tuned enclosure to ensure high-quality audio reproduction that is typically not achievable with shallow mounting depths. Unlike traditional speakers, the SM Series solves the age-old problem of achieving quality audio reproduction from limited mounting depths. By incorporating a tuned, sealed enclosure into the back of the speaker, these speakers can deliver excellent sound even with a shallow mounting depth of only 24mm (15/16"). This allows for installation in areas where many other speakers cannot fit, such as cabinets.

The SM-F65CW speakers come in a stylish white color with a clean aesthetic and a unique shallow mount form factor. They are not only functional but also add a touch of elegance to your vessel.

Key Features:

• Shallow Basket Design - With a mounting depth of only 24mm (15/16"), the SM Series speakers are ideal for installations with limited mounting depth.
• Tuned, Sealed Enclosure Design - The speakers' components are protected from damage, ensuring high-quality audio reproduction that is typically not achievable with such a shallow design.
• Retrofittable - The SM Series speakers have a circular back with a mounting diameter clearance of 130mm (5-1/8"), allowing for easy installation into existing 6.5" speaker cutouts.
• Aesthetic Interior Design - Designed with aesthetics in mind, the SM Series speakers feature a high-end acoustic fabric grille, rounded edges, and contour cues to add style to your vessel.
• IP65 Weatherproof - The SM Series speakers are rated IP65, providing protection against dust and water ingress in the harsh marine environment.

Specifications:

• Cloth Grill cover
• Speaker Enclosure Size: 155mm x 155mm (6-1/8" x 6-1/8")
• Peak Power: 100W
• Driver Size: Tuned and optimized 3"
• Efficiency (1W/1M): 84 dB
• Frequency Response: 150 Hz - 20 kHz
• Nominal Impedance: 4 Ohms
• Cone/Surround Material: Polypropylene with rubber surround
• Mounting Diameter Clearance: 130mm (5-1/8")
• Mounting Depth Clearance: 24mm (15/16")
• Operating Temperature Range: 0-50&degC (32-122&degF)
• Storage Temperature Range: -20-70&degC (-4-158&degF)
• Water and Dust Resistance (IPX rating): IP65
• Warranty: 1 Year

WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to .

Learn More:

• Speaker Enclosure
• Acoustic Grille
• Impedance Matching

Product: Fusion 010-02263-10 Sm-F65Cw Sm Series 6.5" Shallow Mount Square Speakers White

Brand: Fusion

Model: 010-02263-10
