EVGA 210-GQ-1000-V1 Power Supply 1000W Gold Semi Modular

The EVGA 210-GQ-1000-V1 power supply unit is a 1000W ATX power supply in black. It is 80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads. It comes with a 5-year warranty and unparalleled EVGA customer support. The power supply unit features 100% Japanese capacitors to ensure long-term reliability, EVGA ECO Intelligent Thermal Control System to eliminate fan noise at low to medium loads, and active power factor correction (PFC). It is also NVIDIA SLI & AMD Crossfire Ready, with a modular design to reduce clutter and improve airflow. The active clamp +DC to DC design ensures efficient operation, while the 135mm fluid dynamic bearing fan provides whisper silent operation.

Features:

• Total power: 1000W
• AC input voltage: 100 - 240V
• AC input frequency: 50 - 60Hz
• Input current: 16A
• Product color: Black
• On/off switch: Yes
• Mean time between failures (MTBF): 100000 hours
• Weight: 3175g
• Height: 85mm
• Width: 150mm
• Depth: 180mm
• RoHS compliance: Yes
• Certification: TUV, CB, CE, FCC, RCM, cTUVus, WEEE
• Motherboard power connector: 24-pin ATX
• Combined power (+3.3V): 120W
• Max output current (+3.3V): 24A
• Combined power (+5V): 120W
• Max output current (+5V): 24A
• Combined power (+12V): 999.6W
• Max output current (+12V): 83.3A
• Combined power (+5Vsb): 15W
• Max output current (+5Vsb): 3A
• Combined power (-12V): 6W
• Max output current (-12V): 0.5A
• Fan diameter: 135mm
• Number of fans: 1
• Fan location: Top
• Cooling type: Active
• Motherboard power cable length: 600mm
• Number of SATA power connectors: 12
• SATA power cable length: 550mm, 650mm, 750mm
• Peripheral (Molex) power cable length: 550mm, 650mm, 750mm
• Peripheral (Molex) power connectors (4-pin): 3
• Floppy drive power connector: 1
• Floppy disk drive cable length: 100mm
• PCI Express connector: Yes
• PCI Express power cable length: 650mm
• Manual: Yes
• Warranty card: Yes
• Power supply unit (PSU) form factor: ATX
• Purpose: PC
• Operating temperature (T-T): 0 - 50&degC
