EATON 9PX2200GRT UPS 2 KW 8 C13 2 C19

Product Summary:

The Eaton 9PX2200GRT uninterruptible power supply (UPS) is a reliable, versatile, and powerful solution for ensuring continuous power supply in your business. With its double-conversion topology and up to 93% efficiency, this UPS provides constant power conditioning and supports your goal of business continuity. It is designed for scalable deployment, features a graphical LCD for local status updates, and seamlessly integrates with virtualized environments.

Product Details:

• Energy Star certified: Yes
• Form factor: Rackmount/Tower
• Product color: Black, Silver
• UPS topology: Double-conversion (Online)
• Output power capacity: 2200 VA
• Output power: 2000 W
• Width: 440 mm
• Depth: 605 mm
• Height: 86.5 mm
• Weight: 27400 g
• AC outlets quantity: 10
• AC outlet types: C13 coupler, C19 coupler
• Emergency Power Off (EPO): Yes
• Manual: Yes
• Cables included: Input power cable, Output power cable, RS-232, USB cable
• Efficiency: 93%
• Serial interface: Yes
• Serial interface type: RS-232
• RS-232 ports: 1
• USB port: Yes
• USB 2.0 ports quantity: 1
• Power plug: NEMA L6-20P
• Input operation voltage (min): 100 V
• Input operation voltage (max): 276 V
• Input frequency: 50/60 Hz
• Nominal input voltage: 208 V
• Input power factor: 0.99
• Nominal output voltage: 208 V
• Output voltage regulation: 1%
• Output voltage THD: 3%
• Battery technology: Sealed Lead Acid (VRLA)
• Cold start: Yes
• RoHS compliance: Yes
• Certification: IEC 62040-2 Class B Cat C2 / CISPR22 Class B / FCC part 15 Class B / VCCI Class B, CE / cULus / NOM
• Operating temperature (T-T): 0 - 40&degC
• Storage temperature (T-T): -15 - 55&degC
• Operating relative humidity (H-H): 0 - 96%
• Operating altitude: 0 - 3000 m
• Noise level: 47 dB
• Output operation voltage (min): 200 V
• Output operation voltage (max): 240 V
• Surge protection: Yes
• Rack capacity: 2U
• Quick installation guide: Yes
• Display: LCD
• LED indicators: Yes

Learn More:

For more information about uninterruptible power supplies, please visit the Wikipedia page on Uninterruptible Power Supply.

To learn about the Energy Star certification, you can refer to the Wikipedia page on Energy Star.

Product: EATON 9PX2200GRT UPS 2 KW 8 C13 2 C19

Brand: Eaton

Model: 9PX2200GRT

Shipping Weight:

Shipping Height:

Shipping Width:

Shipping Length:
