D-Link DGS-3130-54TS Managed Switch 48 X SFP Ports

The D-Link DGS-3130-54TS Managed Switch is a Lite Layer 3 Stackable Managed Switch designed for secure enterprise or metro Ethernet access networks. It features 48 10/100/1000 Mbps Gigabit Ethernet ports and 4 SFP Gigabit Ethernet ports, making it an ideal access layer solution. The switch supports multicast and enhanced security features to ensure network reliability and maximum uptime.

Features:

• Switch type: Managed
• Switch layer: L3
• Quality of Service (QoS) support: Yes
• Safety certifications: CB, cUL, BSMI, CCC
• Certifications: FCC A, CE A, VCCI A, IC, RCM, BSMI, CCC
• Physical stacking (units): 9
• Virtual stacking (units): 32
• MIB support: RFC 1213, RFC 4188, RFC 1157, RFC 2571-2576, RFC 1907, RFC 1757, RFC 2819, RFC 2021, RFC 1398, RFC 1643, RFC 1650, RFC 2358, RFC 2665, RFC 2674, 802.1p, 2233, 2863 IF MIB, RFC 2618, RFC 2620, RFC 2925, RFC 2674, 4363, RFC 1065, 1066, 1155, 1156, 2578, RFC 1215, RFC 1212, RFC 1215
• Web-based management: Yes
• ARP inspection: Yes
• Basic switching RJ-45 Ethernet ports quantity: 48
• Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
• SFP+ module slots quantity: 4
• Copper ethernet cabling technology: 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T
• Routing protocols: RIP
• USB 2.0 ports quantity: 1
• Power connector: AC-in jack
• Networking standards: IEEE 802.1D, 802.1Q, 802.1p, 802.1s, 802.1v, 802.1w, 802.1x, 802.3ad, 802.3ah, 802.3az, 802.3x
• Head-of-line (HOL) blocking: Yes
• Flow control support: Yes
• Port mirroring: Yes
• Link aggregation: Yes
• DHCP features: DHCP server, DHCP snooping, DHCP relay, DHCP client
• Spanning tree protocol: Yes
• 10G support: Yes
• MAC address table: 16384
• Switching capacity: 216 Gbps
• Forwarding rate: 161 Mpps
• Jumbo frames support: Yes
• VLAN support: Yes
• Number of VLANs: 4000
• Virtual LAN features: Private VLAN, Voice VLAN, Tagged VLAN, MAC address-based VLAN, Port-based VLAN
• Multicast support: Yes
• Fiber optic connector: SFP+
• Security algorithms: SNMP, SNMPv3, SSH-2, SSL/TLS
• Access Control List (ACL): Yes
• SSH/SSL support: Yes
• IGMP snooping: Yes
• Loop protection: Yes
• BPDU filtering/protection: Yes
• Authentication: Guest VLAN, MAC-based authentication, Port-based authentication
• Root protection: Yes
• DoS attack prevention: Yes
• Queue scheduling algorithms: SP, WRR+SP, Weighted Round Robin (WRR)
• Product color: Black, Grey
• Stackable: Yes
• LED indicators: Yes
• Number of fans: 2
• Noise level: 51.9
• Packet buffer memory: 4
• Mean time between failures (MTBF): 478258
• Storage temperature (T-T): -40 - 70
• AC input voltage: 100 - 240
• Operating relative humidity (H-H): 10 - 90
• Storage relative humidity (H-H): 5 - 90
• Heat dissipation: 172.72
• Width: 440 mm
• Depth: 290 mm
