Blue Sea Systems 7046-BSS Panel Mount 187-Series 120A Circuit Breaker

The Blue Sea Systems 7046-BSS Panel Mount 187-Series 120A Circuit Breaker is a high-quality circuit protection device that combines switching and circuit protection into a single device. It is designed to meet SAE J1171 external ignition protection requirements, making it safe for installation aboard gasoline-powered boats.

Featuring a clear, single lever operation, this circuit breaker has a "Trip Free" design, which means it cannot be held "ON" during a fault current condition. It is also waterproof, ensuring reliable performance in wet environments. The recessed mounting holes provide a clean appearance, while the self-trimming case eliminates the need for additional mounting panels or trim bezels.

The Blue Sea Systems 7046-BSS Circuit Breaker is designed with a round case, allowing for easy installation with a standard-sized hole saw. Its large clearance around the terminal studs accepts heavy gauge wire lugs, and the robust 5/16 terminals provide high torque connections. The large lever, with vertical/horizontal orientation, provides clear indication of the trip status.

Features:

• Combines switching and circuit protection into a single device
• All components meet SAE J1171 external ignition protection requirements
• Clear, single lever operation
• "Trip Free" design cannot be held "ON" during fault current condition
• Waterproof
• Recessed mounting holes for clean appearance
• Self-trimming case eliminates the need for mounting panels or trim bezels
• Round case permits easy installation with standard-sized hole saw
• Large clearance around terminal studs accept heavy gauge wire lugs
• Robust 5/16 terminals provide high torque connections
• Large lever with vertical/horizontal orientation provides indication of trip status
• Ignition protected - safe for installation aboard gasoline powered boats

Specifications

• Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free
• Type: Thermally Responsive Bi-Metal Blade
• Case Material: Thermoset Polyester
• Voltage Rating: 48 Volts DC Maximum
• Interrupt Rating:
  • 5,000 Amperes at 12 Volts DC
  • 3,000 Amperes at 24 Volts DC
  • 1,500 Amperes at 42 Volts DC
• Operating Temperature Range: -25&degC to +82&degC

Learn More

• Circuit Breaker on Wikipedia

Product: Blue Sea Systems 7046-BSS Panel Mount 187-Series 120A Circuit Breaker

Brand: Blue Sea Systems

Model: 7046

Shipping Weight: 0.50 lb

Shipping Height: 2.00 in

Shipping Width: 5.00 in

Shipping Length: 8.00 in
