MINIBUS 100 AMP COMMON BUS (BLUE SEA SYSTEMS)

The MINIBUS 100 Amp Common Bus is a versatile and space-saving solution for electronics cabinets and under dashboards. This product features a MiniBus with a 100 Ampere capacity and 5 x 8-32 screw terminals. With its snap-on insulating cover, the MiniBus allows unobstructed wire access while ensuring safety.

The raised bus design of the MiniBus provides easy access to multiple wires on a single screw, eliminating the need for securing nuts. The stainless steel studs allow for high torquing, ensuring excellent electrical contact. The tin-plated copper bus provides maximum conductivity and corrosion resistance.

For added convenience, this MiniBus features recessed mounting holes that eliminate accidental shorts to aluminum and steel mounting surfaces. The captive star-type lock washers meet CE requirements for anti-rotation and eliminate the hassle of handling small, easily dropped parts. The stainless steel Phillips screws not only make installation easier but also provide resistance to stripping.

The base material of the MiniBus is made of reinforced polycarbonate, which is UL 94-VO rated and resistant to high heat. The clear polycarbonate cover material allows for visibility while protecting the terminals. With a continuous amperage rating of 130 Amperes AC/DC and a maximum voltage rating of 300 Volts AC/48 Volts DC, this MiniBus is suitable for various applications.

Product Features:

• MiniBus with 100 Ampere capacity
• 5 x 8-32 screw terminals
• Snap-on insulating cover for unobstructed wire access
• Raised bus design for easy access to multiple wires
• Pressed on busbar eliminates the need for securing nut
• Stainless steel studs for high torquing and excellent electrical contact
• Tin-plated copper bus for maximum conductivity and corrosion resistance
• Recessed mounting holes to prevent accidental shorts
• Captive star-type lock washers for anti-rotation
• Stainless steel Phillips screws for easy installation and resistance to stripping
• UL 94-VO rated reinforced polycarbonate base material for high heat resistance

Specifications:

• Continuous Amperage: 130 Amperes AC/DC
• Maximum Voltage Rating: 300 Volts AC/48 Volts DC
• Bus Material: Tin-Plated Copper CDA 110/UNS11000
• Base Material: Reinforced Polycarbonate
• Cover Material: Clear Polycarbonate
• Weight: 0.17 lb

Learn More:

• Tin-Plated Copper on Wikipedia
• Polycarbonate on Wikipedia

Product: Blue Sea Systems 2315 Minibus 100A Common Busbar 4x10-32 Stud Terminal

Brand: Blue Sea Systems

Model: 2315

Shipping Weight: 0.20 lb

Shipping Height: 1.00 in

Shipping Width: 2.00 in

Shipping Length: 8.00 in
